DN40-DN300
DN350-DN1200
| DN | D | H | d | K | |
| 1.5″ | DN40 | 42.7 | 37.2 | 12.7 | 11.5 |
| 2″ | DN50 | 52.6 | 46.6 | 12.7 | 11.5 |
| 2.5″ | DN65 | 64.4 | 59.4 | 12.7 | 11.5 |
| 3″ | DN80 | 78.8 | 75.1 | 12.7 | 11.5 |
| 4″ | DN100 | 104.1 | 98.2 | 15.9 | 14 |
| 5″ | DN125 | 123.3 | 117.1 | 19.1 | 17 |
| 6″ | DN150 | 155.8 | 148 | 19.1 | 17 |
| 8″ | DN200 | 202.5 | 195.8 | 22.3 | 20 |
| 10″ | DN250 | 250.8 | 243 | 28.7 | 25 |
| 12″ | DN300 | 301.6 | 292.8 | 31.8 | 29 |
| 14″ | DN350 | 333.8 | 326.2 | 31.8 | 29 |
| 16″ | DN400 | 389.6 | 379.8 | 33.5 | 29.15 |
| 18″ | DN450 | 440.5 | 429 | 38.2 | 33.4 |
| 20″ | DN500 | 491.6 | 480.2 | 41.4 | 36.2 |
| 24″ | DN600 | 592.5 | 579.9 | 50.9 | 45 |
| 28″ | DN700 | 695 | 674.4 | 63.6 | 57.1 |
| 32″ | DN800 | 794.7 | 774.6 | 63.6 | 57.1 |
| 36″ | DN900 | 864.7 | 846.2 | 75 | 67.2 |
| 40″ | DN1000 | 965 | 943.7 | 85 | 76.2 |
| 44″ | DN1100 | 1066 | 1047.5 | 95 | 85.2 |
| 48″ | DN1200 | 1160.6 | 1139.9 | 105 | 95.2 |
